AF
Size: a a a
2021 April 15
AF
я же тебе примеры даю, ты уже будь добр под себя попроавь ;)
LS
12 убрал он создал файл
LS
но файл ничем не открывается
AF
разрешение поправил? и надо было не просто убрать а подставить live как у тебя
LS
да поправил
AF
смотри тогда лог при создании файла в терминале, там в принципе всё есть
LS
pi@raspberrypi
:~ $ ffmpeg -y -i rtsp://admin:wqeqweqwe@192.168.55.25:554/live -t 5 -f mp4 -vcodec libx264 -pix_fmt yuv420p -an -vf scale=w=1920:h=1080:force_original_aspect_ratio=decrease -r 15 /opt/iobroker/out2.mp4
ffmpeg version 3.2.15-0+deb9u2 Copyright (c) 2000-2020 the FFmpeg developers
built with gcc 6.3.0 (Raspbian 6.3.0-18+rpi1+deb9u1) 20170516
configuration: --prefix=/usr --extra-version=0+deb9u2 --toolchain=hardened --libdir=/usr/lib/arm-linux-gnueabihf --incdir=/usr/include/arm-linux-gnueabihf --enable-gpl --disable-stripping --enable-avresample --enable-avisynth --enable-gnutls --enable-ladspa --enable-libass --enable-libbluray --enable-libbs2b --enable-libcaca --enable-libcdio --enable-libebur128 --enable-libflite --enable-libfontconfig --enable-libfreetype --enable-libfribidi --enable-libgme --enable-libgsm --enable-libmp3lame --enable-libopenjpeg --enable-libopenmpt --enable-libopus --enable-libpulse --enable-librubberband --enable-libshine --enable-libsnappy --enable-libsoxr --enable-libspeex --enable-libssh --enable-libtheora --enable-libtwolame --enable-libvorbis --enable-libvpx --enable-libwavpack --enable-libwebp --enable-libx265 --enable-libxvid --enable-libzmq --enable-libzvbi --enable-omx --enable-openal --enable-opengl --enable-sdl2 --enable-libdc1394 --enable-libiec61883 --enable-chromaprint --enable-frei0r --enable-libopencv --enable-libx264 --enable-shared
libavutil 55. 34.101 / 55. 34.101
libavcodec 57. 64.101 / 57. 64.101
libavformat 57. 56.101 / 57. 56.101
libavdevice 57. 1.100 / 57. 1.100
libavfilter 6. 65.100 / 6. 65.100
libavresample 3. 1. 0 / 3. 1. 0
libswscale 4. 2.100 / 4. 2.100
libswresample 2. 3.100 / 2. 3.100
libpostproc 54. 1.100 / 54. 1.100
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 46 packets
[h264 @ 0xe1c400] error while decoding MB 29 18, bytestream -5
[h264 @ 0xe1c400] concealing 6020 DC, 6020 AC, 6020 MV errors in P frame
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 7 packets
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 19 packets
Input #0, rtsp, from 'rtsp://admin:qweqweqwe@192.168.55.25:554/live':
Metadata:
title : Media Server
Duration: N/A, start: 0.240000, bitrate: N/A
Stream #0:0: Video: h264 (Main), yuvj420p(pc, bt709, progressive), 1920x1080 [SAR 1:1 DAR 16:9], 25 fps, 25 tbr, 90k tbn, 50 tbc
[swscaler @ 0xe49150] deprecated pixel format used, make sure you did set range correctly
[libx264 @ 0xe58c90] using SAR=1/1
[libx264 @ 0xe58c90] using cpu capabilities: ARMv6 NEON
[libx264 @ 0xe58c90] profile High, level 4.0
[libx264 @ 0xe58c90] 264 - core 148 r2748 97eaef2 - H.264/MPEG-4 AVC codec - Copyleft 2003-2016 - http://www.videolan.org/x264.html - options: cabac=1 ref=3 deblock=1:0:0 analyse=0x3:0x113 me=hex subme=7 psy=1 psy_rd=1.00:0.00 mixed_ref=1 me_range=16 chroma_me=1 trellis=1 8x8dct=1 cqm=0 deadzone=21,11 fast_pskip=1 chroma_qp_offset=-2 threads=6 lookahead_threads=1 sliced_threads=0 nr=0 decimate=1 interlaced=0 bluray_compat=0 constrained_intra=0 bframes=3 b_pyramid=2 b_adapt=1 b_bias=0 direct=1 weightb=1 open_gop=0 weightp=2 keyint=250 keyint_min=15 scenecut=40 intra_refresh=0 rc_lookahead=40 rc=crf mbtree=1 crf=23.0 qcomp=0.60 qpmin=0 qpmax=69 qpstep=4 ip_ratio=1.40 aq=1:1.00
Output #0, mp4, to '/opt/iobroker/out2.mp4':
Metadata:
title : Media Server
encoder : Lavf57.56.101
Stream #0:0: Video: h264 (libx264) ([33][0][0][0] / 0x0021), yuv420p, 1920x1080 [SAR 1:1 DAR 16:9], q=-1--1, 15 fps, 15360 tbn, 15 tbc
Metadata:
encoder : Lavc57.64.101 libx264
Side data:
cpb: bitrate max/min/avg: 0/0/0 buffer size: 0 vbv_delay: -1
Stream mapping:
Stream #0:0 -> #0:0 (h264 (native) -> h264 (libx264))
Press [q] to stop, [?] for help
[h264 @ 0x1021880] error while decoding MB 29 18, bytestream -5
[h264 @ 0x1021880] concealing 6020 DC, 6020 AC, 6020 MV errors in P frameLS
frame= 1 fps=0.0 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 dframe= 3 fps=2.6 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 dframe= 8 fps=4.8 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 d[h264 @ 0x1021880] error while decoding MB 114 26, bytestream -5
[h264 @ 0x1021880] concealing 4975 DC, 4975 AC, 4975 MV errors in P frame
frame= 11 fps=4.9 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 dframe= 15 fps=5.3 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 dframe= 19 fps=5.6 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 d[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 784 packets
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 24 packets
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 4 packets
frame= 21 fps=5.3 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 d[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 25 packets
[rtsp @ 0xe195f0] max delay reached. need to consume packet
[rtsp @ 0xe195f0] RTP: missed 6 packets
[h264 @ 0xf52200] error while decoding MB 16 2, bytestream -9
[h264 @ 0xf52200] concealing 7953 DC, 7953 AC, 7953 MV errors in P frame
frame= 22 fps=4.3 q=0.0 size= 0kB time=00:00:00.00 bitrate=N/A dup=0 dframe= 22 fps=1.9 q=-1.0 Lsize= 688kB time=00:00:01.26 bitrate=4450.0kbits/s dup=0 drop=13 speed=0.111x
video:687kB audio:0kB subtitle:0kB other streams:0kB global headers:0kB muxing overhead: 0.161766%
[libx264 @ 0xe58c90] frame I:1 Avg QP:20.55 size:391373
[libx264 @ 0xe58c90] frame P:9 Avg QP:24.53 size: 28276
[libx264 @ 0xe58c90] frame B:12 Avg QP:29.19 size: 4745
[libx264 @ 0xe58c90] consecutive B-frames: 13.6% 36.4% 13.6% 36.4%
[libx264 @ 0xe58c90] mb I I16..4: 30.1% 12.2% 57.6%
[libx264 @ 0xe58c90] mb P I16..4: 0.0% 0.0% 0.0% P16..4: 23.0% 3.1% 9.9% 0.0% 0.0% skip:64.0%
[libx264 @ 0xe58c90] mb B I16..4: 0.0% 0.0% 0.0% B16..8: 17.3% 1.6% 1.9% direct: 0.8% skip:78.3% L0:51.0% L1:46.5% BI: 2.5%
[libx264 @ 0xe58c90] 8x8 transform intra:12.3% inter:19.0%
[libx264 @ 0xe58c90] coded y,uvDC,uvAC intra: 96.6% 48.2% 11.2% inter: 6.6% 2.4% 0.0%
[libx264 @ 0xe58c90] i16 v,h,dc,p: 6% 5% 71% 19%
[libx264 @ 0xe58c90] i8 v,h,dc,ddl,ddr,vr,hd,vl,hu: 24% 19% 22% 4% 4% 5% 5% 6% 10%
[libx264 @ 0xe58c90] i4 v,h,dc,ddl,ddr,vr,hd,vl,hu: 30% 19% 18% 5% 5% 6% 5% 5% 8%
[libx264 @ 0xe58c90] i8c dc,h,v,p: 54% 19% 23% 3%
[libx264 @ 0xe58c90] Weighted P-Frames: Y:0.0% UV:0.0%
[libx264 @ 0xe58c90] ref P L0: 77.5% 3.8% 16.5% 2.2%
[libx264 @ 0xe58c90] ref B L0: 87.7% 10.9% 1.4%
[libx264 @ 0xe58c90] ref B L1: 98.6% 1.4%
[libx264 @ 0xe58c90] kb/s:3833.43LS
иногда ошибки проскакивают
LS
Создалосб видео на одну секунду
LS
А как увеличить количство кадров?
AF
-r 15
AF
здесь на 25 повысь
AF
должно всё без сучка проскакивать, тогда не будет проблем.
LS
Странно что скриптом видео не обновляется
LS
Он мне шлет старое видео которое создалось в терминале
AF
попробуй уменьшить разрешение, у тебя малина не справляется
LS
Уменьшить в команде?
